GW5048D-ES
Technical Specifications: |
||
|---|---|---|
| AC nominal power (kW) | : | 4.6 |
| Topology | : | transformerless |
| Max. input current DC (A) total | : | 22 |
| MPP max. voltage range input (V) | : | 550 |
| Interface 2 | : | W-Lan |
| Min. temperature ambient (°C) | : | -25 |
| Protection degree | : | IP65 |
| Number of independent MPPT (pcs) | : | 2 |
| Decibel | : | 25 |
| Start input voltage (V) | : | 150 |
| Total number of string inputs | : | 2 |
| Max. short circuit current per MPPT (A) | : | 13.8/13.8 |
| Interface 1 | : | RS485 |
| Battery Connection | : | DC |
| Charging voltage (V) | : | 48-60 |
| Display | : | w/o display |
| Max. short circuit current (A) total | : | 27.6 |
| Charging current (A) | : | 100 |
| Max. input voltage DC (V) | : | 580 |
| Max. input current per MPPT (A). | : | 11.0/11.0 |
| MPP min. voltage range input (V) | : | 125 |
| Max. efficiency (%) | : | 97.6 |
| Max. generator power DC (kWp) | : | 6.65 |
| Max. output current (A) | : | 21.7 |
| Max. AC power (kVA) | : | 5 |
| Feed-in phases | : | 1 |
| European efficiency (%) | : | 97 |
| Integrated DC switch | : | no |
| Min. voltage range input (V) | : | 125 |
| L * W * H Without Packaging (mm) | : | 184.00 * 516.00 * 440.00 |
Product Information
Product Information
Shipping & Returns
Shipping & Returns
GW5048D-ES
GW5048D-ES
Technical Specifications: |
||
|---|---|---|
| AC nominal power (kW) | : | 4.6 |
| Topology | : | transformerless |
| Max. input current DC (A) total | : | 22 |
| MPP max. voltage range input (V) | : | 550 |
| Interface 2 | : | W-Lan |
| Min. temperature ambient (°C) | : | -25 |
| Protection degree | : | IP65 |
| Number of independent MPPT (pcs) | : | 2 |
| Decibel | : | 25 |
| Start input voltage (V) | : | 150 |
| Total number of string inputs | : | 2 |
| Max. short circuit current per MPPT (A) | : | 13.8/13.8 |
| Interface 1 | : | RS485 |
| Battery Connection | : | DC |
| Charging voltage (V) | : | 48-60 |
| Display | : | w/o display |
| Max. short circuit current (A) total | : | 27.6 |
| Charging current (A) | : | 100 |
| Max. input voltage DC (V) | : | 580 |
| Max. input current per MPPT (A). | : | 11.0/11.0 |
| MPP min. voltage range input (V) | : | 125 |
| Max. efficiency (%) | : | 97.6 |
| Max. generator power DC (kWp) | : | 6.65 |
| Max. output current (A) | : | 21.7 |
| Max. AC power (kVA) | : | 5 |
| Feed-in phases | : | 1 |
| European efficiency (%) | : | 97 |
| Integrated DC switch | : | no |
| Min. voltage range input (V) | : | 125 |
| L * W * H Without Packaging (mm) | : | 184.00 * 516.00 * 440.00 |
$203.74
Original: $582.12
-65%GW5048D-ES—
$582.12
$203.74Product Information
Product Information
Shipping & Returns
Shipping & Returns
Description
Technical Specifications: |
||
|---|---|---|
| AC nominal power (kW) | : | 4.6 |
| Topology | : | transformerless |
| Max. input current DC (A) total | : | 22 |
| MPP max. voltage range input (V) | : | 550 |
| Interface 2 | : | W-Lan |
| Min. temperature ambient (°C) | : | -25 |
| Protection degree | : | IP65 |
| Number of independent MPPT (pcs) | : | 2 |
| Decibel | : | 25 |
| Start input voltage (V) | : | 150 |
| Total number of string inputs | : | 2 |
| Max. short circuit current per MPPT (A) | : | 13.8/13.8 |
| Interface 1 | : | RS485 |
| Battery Connection | : | DC |
| Charging voltage (V) | : | 48-60 |
| Display | : | w/o display |
| Max. short circuit current (A) total | : | 27.6 |
| Charging current (A) | : | 100 |
| Max. input voltage DC (V) | : | 580 |
| Max. input current per MPPT (A). | : | 11.0/11.0 |
| MPP min. voltage range input (V) | : | 125 |
| Max. efficiency (%) | : | 97.6 |
| Max. generator power DC (kWp) | : | 6.65 |
| Max. output current (A) | : | 21.7 |
| Max. AC power (kVA) | : | 5 |
| Feed-in phases | : | 1 |
| European efficiency (%) | : | 97 |
| Integrated DC switch | : | no |
| Min. voltage range input (V) | : | 125 |
| L * W * H Without Packaging (mm) | : | 184.00 * 516.00 * 440.00 |
